一、电气性能Electrical
1、阻抗Impedance ：50Ω
2、频率范围Frequency range ：DC~40GHz
3、驻波VSWR ：≤1.20
4、介质耐压Dielectric withstanding voltage ：≤750V rms
5、内导体接触电阻Intemal conductor contact resistance ：≤5mΩ
6、外导体接触电阻External conductor contact resistance ：≤2.5mΩ
7、绝缘电阻Insulation resistance ：≥1000MΩ
二、环境与机械性能Environment and Machinery
1、温度范围 Temperature range ：-65℃~+155℃
2、耐久性Durability ：500cycles
三、材料与镀层Material and Plating
1、内导体Inner conductor ：铍铜镀金/黄铜Beryllium/Brass copper gold plating
2、外导体Outer conductor ：铍铜镀金/黄铜Beryllium/Brass copper gold plating
3、绝缘体Insulator ：聚四氟乙烯PTFE
